CMEX-5f, 5.0 MP digital USB-2 color camera with 1/2.8 inch CMOS sensor
Sensor CMOS 1/2.8 inch with 2560 x 1920 pixels, 5.0 MP
Scan mode Progressive, rolling shutter
Pixel size 2.0 μm x 2.0 μm
Filter RGB
Mount C-mount
Max fps Up to 30 frames per second (2560 x1920 pixels)
Max fps Up to 50 frames per second (1600 x 1200 pixels)
greyscale conversion 8 bits, color rendering 24 bits
Sensitivity >2.0 V/lux-sec @ 550 nm
Exposure Automatic or manual, from 1 ms to 2000 ms
White balance Automatic / Manual
Dynamic range 72 db.
Data interface USB 2.0 at 480 Mb/s
Operation 0 – 60° C, 10-85 % humidity. Storage temperature -20 to 70° Celsius
Supplied with 0.45x objective with C-mount, USB 2.0 cable, 30 and 30.5 mm adapters for
stereo microscopes, 76 x 24 mm calibration slide (1mm/100), ImageFocus Plus software,
carton box
Software Windows 7/8/10/11 (32 and 64 bit configurations) and Mac OS
Compatible with Intel Core 2, 2.8 Gaz or higher, 4 GB, USB-2 port, 17 inch display
