BS.1152-EPLPHi - Euromex binocular microscope for phase contrast

Eyepieces HWF 10x/20 mm eyepieces
Head Binocular head, Siedentopf type, 30° inclined tubes. Interpupillary distance 48-75 mm. Dioptre adjustment on left tube
Nosepiece Reversed quintuple revolving nosepiece on ball-bearings
Objectives E-plan phase EPLPHi 10x, 20x, S40x, S100x oil immersion infinity corrected IOS objectives for phase contrast
All optics are anti-fungus treated and anti-reflection coated for maximum light throughput
Stand Coaxial coarse and fine adjustments with 180 graduations. Precision 1.1 μm, 0.2 mm per rotation. Total travel approximately 18 mm. Friction adjustment
Stage Plain 131 x 152/197 mm rackless stage with 77 x 36 mm mechanical rackless stage
Condensor Height adjustable Zernike condenser N.A. 1.25 with iris diaphragm and filter holder
Illumination 1,5 W NeoLED™ Kohler illumination. Internal power supply 100-240 V (CE)
Packaging Supplied with power cord, dust cover and 5 ml immersion oil in styrofoam case and without rechargeable AA-type batteries
